KAG07047 Kagero Topdrawings - Renault FT & M1917

20 pages

The world�??s first modern tank, a pioneering vehicle whose basic features can be found on today�??s modern tanks. FT was an undeniable success. A large number of FTs was provided to most Western front units by 1918, and they were involved in all major offensives, successfully crossing over trenches as intended, but also driving through forests. Renault produced two variants of the FT, the machine-gun model, which was more common, and a short-barreled 37 mm Puteaux SA 18 gun. Those models were identified by their definitive Omnibus turret, multifaceted or rounded with bent metal plates. By December 1917 3100 FTs were to be produced with the Omnibus turret, in both types. The FT had some flaws of the first series, including the radiator fan belt and cooling system problems.

In 1919 a new redesigned version was proposed by Renault, including a more powerful engine, a long-barreled Puteaux gun and additional cases fitted in their tracks. It was successfully exported throughout the world. Some of them were immediately put into action, like the Finnish and Polish versions against the Soviets
